Transmetteur de Température et d'Humidité - ONST
Bass Instruments' ONST series Temperature and Humidity Transmitters are economical measurement instruments designed to measure temperature and humidity in the air with an integrated temperature and humidity probe. They provide temperature and humidity parameters as electrical outputs. The temperature measurement unit and the sensor's signal output are fully isolated. These transmitters offer safety, an attractive appearance, and easy installation. They can be selected in either wall-mount or duct-mount configurations. A display can be added as an option.
APPELEZ MAINTENANT
WHATSAPP
FORMULAIRE DE DEMANDE
| Connection | Wall Mount or Duct Mount |
| Temperature | -40...120°C |
| Humidity | 0...100% RH |
| Output | 4-20 mA / 0-10 VDC / RS485 MODBUS |
| Power Supply | 10...30 VDC |
| Accuracy | ± 0.4% and ± 2% |
| Response Time | i<25S |
| Display | LCS |
| Measurement Range | 10:1 |
| Protection | IP54 (Sensor: IP20) |
| Features |
Compact Design Long-Term Stability Economical Outdoor Use |
